Heidelberg's Prinect Easy Control is a new and simple-to-use color measurement device for the.
Speedmaster SM 74 with Prinect Press Center and Prinect Press Center Compact.
The functions in Prinect Easy Control enable even printers with no previous experience fast and easy entry into color measurement technology.

... 1. Spectrophotometer with polarization filter for measuring densities and tonal values
As with all Prinect color measurement devices, Prinect Easy Control also carries out spectral measurements of print control strips. Colorimetric L*a*b* values are measured without a polarization filter. Densities and tonal values can be measured either with or without polarization filters - both in just one step. This means Prinect Easy Control complies with ISO standards as well as the process standard for offset printing (PSO) specifications.

2. Integrated in Prinect Press Center and Prinect Press Center Compact
It is integrated in the press console, therefore does not reduce the pressman's working space, and is operated with the Prinect Press Center touch screen. All ink zones are regulated online.

3. Applications
Prinect Easy Control is for the Speedmaster SM 74 with a minimum of 2 and a maximum of 6 printing units for straight as well as perfecting printing operations. All ink zones are adjusted simultaneously after the pressman has given his OK
